ABB ACQ580-01 User Manual

13
R1-
R4
R5
R6-
R9
EN
DA
DE
ES
FI
FR
IT
NL
PL
PT
RU
SV
TR
ZH
Type
ACQ580
-01-
Min. short-
circuit
current
1)
Input
current
uR or aR (DIN 43653 bolted tags)
Nominal
current
I
2
t Voltage
rating
Bussmann
type
IEC 60269
size
A A A A
2
s V
3-phase U
N
= 400 or 480 V
02A7-4 65 2.6 25 130 690 170M1311 000
03A4-4 65 3.3 25 130 690 170M1311 000
04A1-4 65 4.0 25 130 690 170M1311 000
05A7-4 65 5.6 25 130 690 170M1311 000
07A3-4 65 7.2 25 130 690 170M1311 000
09A5-4 65 9.4 25 130 690 170M1311 000
12A7-4 65 12.6 25 130 690 170M1311 000
018A-4 120 17.0 40 460 690 170M1313 000
026A-4 120 25.0 40 460 690 170M1313 000
033A-4 170 32.0 63 1450 690 170M1315 000
039A-4 170 38.0 63 1450 690 170M1315 000
046A-4 280 45.0 80 2550 690 170M1316 000
062A-4 380 62 100 4650 690 170M1417 000
073A-4 480 73 125 8500 690 170M1318 000
088A-4 700 88 160 16000 690 170M1319 000
106A-4 700 106 200 15000 690 170M3015 1
145A-4 1000 145 250 28500 690 170M3016 1
169A-4 1280 169 315 46500 690 170M3017 1
206A-4 1520 206 350 68500 690 170M3018 1
246A-4 2050 246 450 105000 690 170M5009 2
293A-4 2200 293 500 145000 690 170M5010 2
363A-4 3100 363 630 275000 690 170M5012 2
430A-4 3600 430 700 405000 690 170M5013 2
3AXD00000586715.xls L
1)
Minimum short-circuit current of the installation
