186 Additional parameter data
13.12 AO1 source Analog
src
--1 = 1
13.13 AO1 forced value Real 0.000…22.000 or
0.000…11000 V
mA 1000 = 1 mA
13.15 AO1 unit selection List 2, 10 - 1 = 1
13.16 AO1 filter time Real 0.000…30.000 s 1000 = 1 s
13.17 AO1 source min Real -32768.0…32767.0 - 10 = 1
13.18 AO1 source max Real -32768.0…32767.0 - 10 = 1
13.19 AO1 out at AO1 src min Real 0.000…22.000 or
0.000…11000 V
mA 1000 = 1 mA
13.20 AO1 out at AO1 src max Real 0.000…22.000 or
0.000…11000 V
mA 1000 = 1 mA
13.21 AO2 actual value Real 0.000…22.000 mA 1000 = 1 mA
13.22 AO2 source Analog
src
--1 = 1
13.23 AO2 forced value Real 0.000…22.000 mA 1000 = 1 mA
13.26 AO2 filter time Real 0.000…30.000 s 1000 = 1 s
13.27 AO2 source min Real -32768.0…32767.0 - 10 = 1
13.28 AO2 source max Real -32768.0…32767.0 - 10 = 1
13.29 AO2 out at AO2 src min Real 0.000…22.000 mA 1000 = 1 mA
13.30 AO2 out at AO2 src max Real 0.000…22.000 mA 1000 = 1 mA
13.91 AO1 data storage Real -327.68…327.67 - 100 = 1
13.92 AO2 data storage Real -327.68…327.67 - 100 = 1
21 Start/stop mode
21.01 Start mode List 0…2 - 1 = 1
21.02 Magnetization time Real 0…10000 ms 1 = 1 ms
21.19 Scalar start mode List 0…4 - 1 = 1
21.22 Start delay Real 0.00…60.00 s 100 = 1 s
21.23 Smooth start Real 0...2 - 1 = 1
21.24 Smooth start current Real 0.0…100.0 % 100 = 1
21.25 Smooth start speed Real 2.0…100.0 % 100 = 1
23 Speed reference ramp
23.01 Speed ref ramp input Real -30000.00…30000.00 rpm 100 = 1 rpm
23.02 Speed ref ramp output Real -30000.00…30000.00 rpm 100 = 1 rpm
23.12 Acceleration time 1 Real 0.000…1800.000 s 1000 = 1 s
23.13 Deceleration time 1 Real 0.000…1800.000 s 1000 = 1 s
24 Speed reference conditioning
24.01 Used speed reference Real -30000.00…30000.00 rpm 100 = 1 rpm
24.02 Used speed feedback Real -30000.00…30000.00 rpm 100 = 1 rpm
24.03 Speed error filtered Real -30000.0…30000.0 rpm 100 = 1 rpm
24.12 Speed error filter time Real 0…10000 ms 1 = 1 ms
25 Speed control
25.01 Torque reference speed control Real -1600.0…1600.0 % 10 = 1%
25.02 Speed proportional gain Real 0.00…250.00 - 100 = 1
25.03 Speed integration time Real 0.00…1000.00 s 100 = 1 s
25.04 Speed derivation time Real 0.000…10.000 s 1000 = 1 s
25.05 Derivation filter time Real 0…10000 ms 1 = 1 ms
25.30 Flux adaptation enable List 0...1 - -
25.53 Torque prop reference Real -30000.0…30000.0 % 10 = 1%
25.54 Torque integral reference Real -30000.0…30000.0 % 10 = 1%
25.55 Torque deriv reference Real -30000.0…30000.0 % 10 = 1%
28 Frequency reference chain
28.01 Frequency ref ramp input Real -500.00…500.00 Hz 100 = 1 Hz
28.02 Frequency ref ramp output Real -500.00…500.00 Hz 100 = 1 Hz
28.72 Freq acceleration time 1 Real 0.000…1800.000 s 1000 = 1 s
28.73 Freq deceleration time 1 Real 0.000…1800.000 s 1000 = 1 s
30 Limits
30.01 Limit word 1 PB 0b0000…0b1111 - 1 = 1
No. Name Type Range Unit FbEq32
