Chapter 3 – ACS 502 Installation Instructions
ACS 502 Installation & Start-up Manual 3-5
Output Power Wiring
Table 3-3 shows the output wire sizes for the ACS 502.
Table 3-3 ACS 502 Output Wire Sizes
* Indicates 2 pole per phase for terminal information and 2 conductor for wire
size information.
Table 3-4 shows ground lug wire sizes for the ACS 502.
Table 3-4 ACS 502 Ground Lug Wire Sizes
Amp Range Overload Terminal Block
29.3 – 60.0 #12 – #2 #6-250MCM
57.1 – 100.0 #10 – 2/0 #6-250MCM
98.0 – 180.0 #6 – 250MCM #6-250MCM
175.0 – 220.0 * #6 – 4/0 * #6-4/0
221.0 – 465.0 * #6 – 4/0 * #6-4/0
Drive Type Ground Lug
ACS 502-050 to ACS 502-350 #6-350MCM
