Appendix A – ACS/ACC/ACP 604/607 Technical Data
A-2 ACx=ACS/ACC/ACP ACS/ACC/ACP 604/607 Drives
The table continues from previous page.
Pump and Fan
Use (Squared
Load)
P
N
ACS 604/607
Type
I
2Nsq
[A]
P
N
[kW]
[Hp]
Frame
Type
Three-phase supply voltage 380 V, 400 V or 415 V
ACS 604/607-0100-3 178 90 125 R7
ACS 604/607-0120-3 200 110 (100) 150
ACS 604/607-0140-3 260 132 200 R8
ACS 604/607-0170-3 300 160 250
ACS 604/607-0210-3 375 200 300
ACS 604/607-0260-3 480 250 350 R9
ACS 604/607-0320-3 510 315 (265) 400
Three-phase supply voltage 380 V, 400 V, 415 V, 440
V, 460 V, 480 V or 500 V
ACS 604/607-0120-5 164 110 150 R7
ACS 604/607-0140-5 193 132 200
ACS 604/607-0170-5 240 160 250 R8
ACS 604/607-0210-5 285 200 300
ACS 604/607-0260-5 345 250 350
ACS 604/607-0320-5 460 315 400 R9
ACS 604/607-0400-5 490 400 (335) 500
Normal use (10% overload capacity): Heavy-duty use (50% or 100% overload capacity*):
I
2N
rated rms output current
I
2hd
rated rms output current
I
2Nmax
rms overload current (allowed for one minute
every 10 minutes):
I
2Nmax
(1/10 min) = 1.1 ·
I
2N
I
2Nmax
(2/15 s) = 1.5 ·
I
2N
(400 and 500 VAC
units)
I
2hdmax
rms overload current (allowed for one minute
every 10 minutes or 2 seconds every 15
seconds) Maximum current depends on
parameter setting, refer to
Firmware Manual
.
I
2hdmax
(1/10 min) = 1.5 ·
I
2hd
I
2hdmax
(2/15 s) = 2.0 ·
I
2hd
(400 and 500 VAC
units) or 1.5 ·
I
2hd
(690 VAC units)
S
N
rated apparent output power
S
hd
rated apparent output power
P
N
typical motor power. The power ratings in kW
apply to most IEC 34 motors. The power
ratings in HP apply to most four pole NEMA
rated motors.
P
hd
typical motor power. The power ratings in kW
apply to most IEC 34 motors. The power
ratings in HP apply to most four pole NEMA
rated motors.
Pump and Fan Use (Squared Load): no overload capacity
I
2Nsq
P
N
rated rms output current
typical motor power. The power ratings in kW
apply to most IEC 34 motors. The power
ratings in HP apply to most four pole NEMA
rated motors.
The current ratings are the same regardless of the supply
voltage within one voltage range. The
rated current of the ACx 60x must be higher than or equal to
the rated motor current to achieve the rated motor power
given in the table
.
Note 1: The maximum allowed motor shaft power is limited
to 1.5 · P
hd
. If the limit is exceeded, the motor torque and the
I
2hdmax
2/15 s current is automatically restricted. The function
protects the input bridge of the ACS 600 against overload.
Note 2: The load capacity (current and power) decreases if
the installation site altitude exceeds 1000 metres, or if the
ambient temperature exceeds 40 °C (or 35 °C with ACx 60x-
0120-03 and ACx 60x-0140-05 units in Pump and Fan Use).
See Output Current Temperature Derating on page
A-3
.
Note 3: The Pump and Fan rating is not to be used with dv/
dt filters. Usually dv/dt filters are needed at the output of 525
V to 690 V units with random wound motors. No dv/dt filters
are usually required with form wound motors.
Notes concerning Pump and Fan Use only
Pump and Fan rating is available for ACS 600 with Standard
and Pump and Fan Control Application Programs.
To Next Page
