58 ACS510 User’s Manual
Start-Up
2613
USER F2
0.0…500.0 Hz /
+N688:0.0...50.0 Hz /
+N689:0.0...55.0 Hz
0.1 Hz 20.0 Hz /
+N688:20.0 Hz /
+N689:22.0 Hz
2614
USER U3
0...480 V 1 V 228 V
2615
USER F3
0.0…500.0 Hz /
+N688:0.0...50.0 Hz /
+N689:0.0...55.0 Hz
0.1 Hz 30.0 Hz /
+N688:30.0 Hz /
+N689:33.0 Hz
2616
USER U4
0...480 V 1 V 304 V
2617
USER F4
0.0…500.0 Hz /
+N688:0.0...50.0 Hz /
+N689:0.0...55.0 Hz
0.1 Hz 40.0 Hz /
+N688:40.0 Hz /
+N689:44.0 Hz
2618
FW VOLTAGE
190...480 V 1 V 380 V
2619
DC STABILIZER 0…1 1 0
Group 30: Fault Functions
3001
AI<MIN FUNCTION 0…3 1 0
3002
PANEL COMM ERR 1…3 1 1
3003 EXTERNAL FAULT 1-6…6 1 0
3004
EXTERNAL FAULT 2-6…6 1 0
3005
MOT THERM PROT 0 = NOT SEL, 1 = FAULT, 2 = WARNING 11 (FAULT)
3006 MOT THERM TIME 256…9999 s 1 1050 s
3007
MOT LOAD CURVE 50…150% 1 100%
3008
ZERO SPEED LOAD 25…150% 1 70%
3009 BREAK POINT FREQ 1…250 Hz 1 35 Hz
3010
STALL FUNCTION 0…2 1 0 (NOT SEL)
3011
STALL FREQUENCY 0.5…50.0 Hz 0.1 Hz 20.0 Hz
3012 STALL TIME 10…400 s 1 s 20 s
3017
EARTH FAULT 0 = DISABLE, 1 = ENABLE 11 (ENABLE)
3018
COMM FAULT FUNC 0 = NOT SEL, 1 = FAULT, 2 = CONST SP 7,
3 =
LAST SPEED
10 (NOT SEL)
3019
COMM FAULT TIME 0.0…60.0 s 0.1 s 10.0 s
3021 AI1 FAULT LIMIT 0.0…100.0% 0.1% 0.0%
3022
AI2 FAULT LIMIT 0.0…100.0% 0.1% 0.0%
3023
WIRING FAULT 0 = DISABLE, 1 = ENABLE 11
3024
CB TEMP FAULT
0…1 1 1
Group 31: Automatic Reset
3101
NUMBER OF TRIALS 0…5 1 5
3102
TRIAL TIME 1.0…600.0 s 0.1 s 30.0 s
3103
DELAY TIME 0.0…120.0 s 0.1 s 6.0 s
3104
AR OVERCURRENT 0 = DISABLE, 1 = ENABLE 11
3105
AR OVERVOLTAGE 0 = DISABLE, 1 = ENABLE 11
3106
AR UNDERVOLTAGE 0 = DISABLE, 1 = ENABLE 11
3107
AR AI<MIN 0 = DISABLE, 1 = ENABLE 11
3108
AR EXTERNAL FLT 0 = DISABLE, 1 = ENABLE 11
Group 32: Supervision
3201
SUPERV 1 PARAM 100…159 1 103
3202
SUPERV 1 LIM LO --0
Code Name Range Resolution Default User S
