Introduction to this manual
21
Installation and commissioning flowchart
Task See
Identify the frame size of your drive: R2, R3, R4, R5
or R6.
Technical data: IEC data or NEMA data
Plan the installation.
Check the ambient conditions, ratings, required
cooling air flow, input power connection, compatibility
of the motor, motor connection, and other technical
data.
Select the cables.
Technical data
Planning the electrical installation
For compliance with the European Union EMC
Directive, see Technical data: CE marking
Option manual (if optional equipment is
included)
Unpack and check the units.
Check that all necessary option modules and
equipment are present and correct.
Only intact units may be started up.
Mechanical installation: Unpacking the unit.
If the converter has been non-operational for
more than one year, the converter DC link
capacitors need to be reformed. See Converter
module capacitor reforming instructions
(3BFE64059629 [English]).
If the drive is about to be connected to an IT
(ungrounded) system, check that the drive is not
equipped with EMC filtering intended for grounded
systems.
Product overview: Type code
IT (ungrounded) systems
Check the installation site. Mechanical installation: Before installation
Technical data
Install the drive on a wall or in a cabinet. Mechanical installation
Route the cables. Planning the electrical installation: Routing the
cables
For compliance with the European Union EMC
Directive, see Technical data: CE marking.
