Parameters
3ADW000480R0101 DCS880 Quick guide e a
Parameters
What this chapter contains
The chapter describes the parameters and signals of the firmware.
Terms and abbreviations
Type of parameter that is the result of a measurement or calculation by the drive, or
contains status information. Most signals are read-only, but some (especially counter-type
The default value of a parameter.
16-bit fieldbus equivalent: The scaling between the value shown on the panel and the
integer used in communication when a 16-bit value is selected for transmission to an
external system.
A dash (-) indicates that the parameter is not accessible in 16-bit format.
The value is taken from another parameter.
Choosing “Other” displays a parameter list in which the user can specify the source
The value is taken from a specific bit in another parameter.
Choosing “Other” displays a parameter list in which the user can specify the source
A user-adjustable operating instruction for the drive.
Summary of parameter groups
Basic signals for monitoring the drive.
Values of references received from various sources.
Information on warnings and faults that occurred last. For explanations of
individual warning and fault codes.
Various run-time-type counters and measurements related to drive
maintenance.
06 Control and status words
Drive control, status and event words.
The drive’s hardware and firmware information.
Configuration of digital inputs and relay outputs.
Configuration of digital input/outputs and frequency inputs/outputs.
Configuration of standard analog inputs.
Configuration of standard analog outputs.
14 I/O extension module 1
Configuration of I/O extension module 1.
15 I/O extension module 2
Configuration of I/O extension module 2.
16 I/O extension module 3
Configuration of I/O extension module 3.
Selection of local and external control locations and operating modes.
Start/Stop/Direction and run/start/jog enable signal source selection.
Positive/Negative reference enable source selection. Breaker and
acknowledge source selection.
Start and stop modes, emergency stop mode and zero speed.
22 Speed reference selection
Speed reference selection and motor potentiometer settings.
Speed reference ramp settings (programming of the acceleration and
deceleration rates for the drive).
24 Speed reference conditioning
Speed error calculation, speed error window control configuration and
speed error (Δn) step.
Speed controller settings.
26 Torque reference chain
Settings for the torque reference chain.
27 Armature current control
Settings for the armature current control chain.
28 EMF and field current control
Settings for the EMF and field current control chain.
Settings for 12-pulse and hardparallel.
