18 OI/DHH805-EN Rev. D | Handheld communicator Model DHH805-A
7 HART
®
Communication
7.4 Generic HART
®
Commands according to protocol Revision
DHH805 is able to communicate with HART
®
Revision 5, 6 and 7. Here below the list of Generic Commands according to the
protocol revision.
HART 5 HART 6 HART 7
command: 0 READ UNIQUE IDENTIFIER command: 0 READ UNIQUE IDENTIFIER command: 0 READ UNIQUE IDENTIFIER
command: 1 READ PRIMARY VARIABLE command: 1 READ PRIMARY VARIABLE command: 1 READ PRIMARY VARIABLE
command: 2 READ P. V. CURRENT AND
PERCENT OF RANGE
command: 2 READ P. V. CURRENT AND
PERCENT OF RANGE
command: 2 READ LOOP CURRENT AND
PERCENT OF RANGE
command: 3 READ DYNAMIC VARIABLES AND
P. V. CURRENT
command: 3 READ DYNAMIC VARIABLES AND
P. V. CURRENT
command: 3 READ DYNAMIC VARIABLES AND
LOOP CURRENT
command: 6 WRITE POLLING ADDRESS command: 6 WRITE POLLING ADDRESS command: 6 WRITE POLLING ADDRESS
command: 11 READ UNIQUE IDENTIFIER
ASSOCIATED WITH TAG
command: 11 READ UNIQUE IDENTIFIER
ASSOCIATED WITH TAG
command: 11 READ UNIQUE IDENTIFIER
ASSOCIATED WITH TAG
command: 12 READ MESSAGE command: 12 READ MESSAGE command: 12 READ MESSAGE
command: 13 READ TAG, DESCRIPTOR, DATE command: 13 READ TAG, DESCRIPTOR, DATE command: 13 READ TAG, DESCRIPTOR, DATE
command: 14 READ PRIMARY VARIABLE
SENSOR INFORMATION
command: 14 READ PRIMARY VARIABLE
SENSOR INFORMATION
command: 14 READ PRIMARY VARIABLE
SENSOR INFORMATION
command: 15 READ PRIMARY VARIABLE
OUTPUT INFORMATION
command: 15 READ PRIMARY VARIABLE
OUTPUT INFORMATION
command: 15 READ PRIMARY VARIABLE
OUTPUT INFORMATION
command: 16 READ FINAL ASSEMBLY NUMBER command: 16 READ FINAL ASSEMBLY NUMBER command: 16 READ FINAL ASSEMBLY NUMBER
command: 17 WRITE MESSAGE command: 17 WRITE MESSAGE command: 17 WRITE MESSAGE
command: 18 WRITE TAG, DESCRIPTOR, DATE command: 18 WRITE TAG, DESCRIPTOR, DATE command: 18 WRITE TAG, DESCRIPTOR, DATE
command: 19 WRITE FINAL ASSEMBLY
NUMBER
command: 19 WRITE FINAL ASSEMBLY
NUMBER
command: 19 WRITE FINAL ASSEMBLY
NUMBER
command: 34 WRITE PV DAMPING VALUE command: 7 READ LOOP CONFIGURATION command: 7 READ LOOP CONFIGURATION
command: 35 WRITE PRIMARY VARIABLE
RANGE VALUES
command: 8 READ DYNAMIC VARIABLE
CLASSIFICATIONS
command: 8 READ DYNAMIC VARIABLE
CLASSIFICATIONS
command: 36 SET PRIMARY VARIABLE UPPER
RANGE VALUE
command: 20 READ LONG TAG command: 20 READ LONG TAG
command: 37 SET PRIMARY VARIABLE LOWER
RANGE VALUE
command: 21 READ UNIQUE IDENTIFIER
ASSOCIATED WITH LONG TAG
command: 21 READ UNIQUE IDENTIFIER
ASSOCIATED WITH LONG TAG
command: 39 EEPROM CONTROL command: 22 WRITE LONG TAG command: 22 WRITE LONG TAG
command: 40 ENTER/EXIT FIXED PRIMARY
VARIABLE CURRENT MODE
command: 34 WRITE PRIMARY VARIABLE
DAMPING VALUE
command: 34 WRITE PRIMARY VARIABLE
DAMPING VALUE
command: 44 WRITE PRIMARY VARIABLE UNITS command: 35 WRITE PRIMARY VARIABLE
RANGE VALUE
command: 35 WRITE PRIMARY VARIABLE
RANGE VALUE
command: 45 TRIM PRIMARY VARIABLE
CURRENT DAC ZERO
command: 36 SET PRIMARY VARIABLE UPPER
RANGE VALUE
command: 36 SET PRIMARY VARIABLE UPPER
RANGE VALUE
command: 46 TRIM PRIMARY VARIABLE
CURRENT DAC GAIN
command: 37 SET PRIMARY VARIABLE LOWER
RANGE VALUE
command: 37 SET PRIMARY VARIABLE LOWER
RANGE VALUE
command: 108 WRITE BURST MODE
COMMAND NUMBER
command: 38 RESET CONFIGURATION
CHANGED FLAG
command: 38 RESET CONFIGURATION
CHANGED FLAG
command: 109 BURST MODE CONTROL command: 39 EEPROM CONTROL command: 39 EEPROM CONTROL
command: 41 PERFORM TX SELF TEST command: 40 ENTER/EXIT FIXED CURRENT MODE command: 40 ENTER/EXIT FIXED CURRENT MODE
command: 43 SET PRIMARY VARIABLE TO
ZERO
command: 43 SET PRIMARY VARIABLE TO
ZERO
command: 44 WRITE PRIMARY VARIABLE UNITS command: 44 WRITE PRIMARY VARIABLE UNITS
command: 45 TRIM PRIMARY VARIABLE
CURRENT DAC ZERO
command: 45 TRIM PRIMARY VARIABLE
CURRENT DAC ZERO
command: 46 TRIM PRIMARY VARIABLE
CURRENT DAC GAIN
command: 46 TRIM PRIMARY VARIABLE
CURRENT DAC GAIN
command: 108 WRITE BURST MODE
COMMAND NUMBER
command: 108 WRITE BURST MODE
COMMAND NUMBER
command: 109 BURST MODE CONTROL command: 109 BURST MODE CONTROL
command: 41 PERFORM TX SELF TEST command: 41 PERFORM TX SELF TEST
command: 42 PERFORM DEVICE RESET command: 42 PERFORM DEVICE RESET
