NoteArt. no.Equipment
These procedures include refer-
ences to the tools required.
Other tools and procedures may
be required. See references to
these procedures in the step-by-
step instructions below.
Inspecting, oil level gearbox, axis 1
Use this procedure to inspect the oil level in gearbox axis 1.
NoteAction
WARNING
Handling gearbox oil involves several safety risks.
Before proceeding, please read the safety informa-
tion in the section WARNING - Safety risks during
work with gearbox lubricants (oil or grease) on
page 50.
1
DANGER
Turn off all:
• electric power supply
• hydraulic pressure supply
• air pressure supply
to the robot, before entering the robot working area.
2
Shown in figure Location of gear-
box on page 104.
Open the oil plug, inspection.3
Required oil level: max. 10 mm below the oil plug
hole.
4
Where to find type of oil and total
amount is detailed in Type and
amount of oil in gearboxes on
page 127.
Add oil if required.5
Further information about how to
fill with oil is found in section
Changing oil, axis-1 gearbox on
page 129.
Tightening torque:Refit the oil plug, inspection.6
3HAC039838-001 Revision: C 105
© Copyright 2013 ABB. All rights reserved.
3 Maintenance
3.3.1 Inspecting, oil level gearbox axis 1
Continued
