Functions
Chapter 10
162
1SFC132003M0201
10:58 Analog output, reference
Path in menu:
Menu/SETTINGS/Functional Settings/
Analog Output /Anl Ref
With this parameter it is possible to set the unit and the range
of the signal to output. This selected range will be the
physical output from the softstarter. This range should be
selected to suit the analog meter or the PLC that uses this
signal as its input. The possible options are:
• 0-10 V
• 0-20 mA
• 4-20 mA
If for instance 4-20 mA is selected, then this range will
represent 0-100% of the output signal, for instance the
current of the motor.
10:59 Analog output, type of value
Path in menu:
Menu/SETTINGS/Functional Settings/
Analog Output /Anl Type
With this parameter it is possible to set which type of value
that should be the output of the analog output. The possible
types of values are:
I Amp Current of the motor
U Volt Main voltage
P kW Active power kW
P hp Active power hp
Q kVAr Reactive power
S kVA Apparent power
TmpMot Calculated temperature of the motor
TmpSCR Calculated temperature of the SCR
cosPhi Power factor
Parameter
text
Default value Setting range Description
Anl Ref 4...20 mA 0...10V, 0...20mA,
4...20mA
The type of the
output signal of
the analog out-
put
