Local man machine
communication
ABB Network Partner AB
1MRK 580 156-XEN
Page 3 - 27
Version 1.0-00
6 Data window
Use the data windows and branches to perform these tasks:
• Reading information
• Configuration
• Setting parameters
Fig. 8 Data window, general setting (8a) and typical example (8b)
Row one is the same as in the menu windows.
Row two displays the name of a parameter.
Rows three and four provide more information about the value in the
parameter.
The left and right arrow in the bottom row indicate that more data is avail-
able in the same menu branch. Select the right or left arrow button once or
several times to get access to the data.
Fig. 8b shows the data window that appears on the display during the set-
ting procedure for Zone 1 of the distance protection. There is only one
value relevant for the impedance (X1 = 15,00 Ohms). The right arrow
indicates that additional parameters are available for Zone 1 (reach in
resistive direction, time delay, and so on).
.path1/path2
Data name=
Data 1
Data 2
a)
.Imped/Zone1
X1
=
15.00 Ohm
V
b)
(X80156-8)
V
V
