10.11.4 Settings
Table 247: I103IEDCMD Non group settings (basic)
Name
Values (Range) Unit Step Default Description
FunctionType 1 - 255 - 1 255 Function type (1-255)
10.12 Function commands user defined for IEC
60870-5-103 I103USRCMD
10.12.1 Functionality
I103USRCMD is a command block in control direction with user defined output
signals. These function blocks include the FunctionType parameter for each block in
the private range, and the Information number parameter for each output signal.
10.12.2 Function block
IEC10000284-1-en.vsd
I103USRCMD
BLOCK ^OUTPUT1
^OUTPUT2
^OUTPUT3
^OUTPUT4
^OUTPUT5
^OUTPUT6
^OUTPUT7
^OUTPUT8
IEC10000284 V1 EN
Figure 160: I103USRCMD function block
10.12.3 Signals
Table 248: I103USRCMD Input signals
Name
Type Default Description
BLOCK BOOLEAN 0 Block of commands
Table 249: I103USRCMD Output signals
Name
Type Description
OUTPUT1 BOOLEAN Command output 1
OUTPUT2 BOOLEAN Command output 2
OUTPUT3 BOOLEAN Command output 3
OUTPUT4 BOOLEAN Command output 4
OUTPUT5 BOOLEAN Command output 5
Table continues on next page
Section 10 1MRK 511 287-UEN A
Control
336
Technical manual
