12.4.3.4 Settings
A1RADR - A3RADR Settings
Setting tables for A1RADR, A2RADR and A3RADR are similar except for channel
numbers.
• A1RADR, channel01 - channel10
• A2RADR, channel11 - channel20
• A3RADR, channel21 - channel30
Table 382: A1RADR Non group settings (basic)
Name Values (Range) Unit Step Default Description
Operation01 Off
On
- - Off Operation On/Off
Operation02 Off
On
- - Off Operation On/Off
Operation03 Off
On
- - Off Operation On/Off
Operation04 Off
On
- - Off Operation On/Off
Operation05 Off
On
- - Off Operation On/Off
Operation06 Off
On
- - Off Operation On/Off
Operation07 Off
On
- - Off Operation On/Off
Operation08 Off
On
- - Off Operation On/Off
Operation09 Off
On
- - Off Operation On/Off
Operation10 Off
On
- - Off Operation On/Off
FunType1 0 - 255 - 1 0 Function type for analog channel 1
(IEC-60870-5-103)
InfNo1 0 - 255 - 1 0 Information number for analog channel 1
(IEC-60870-5-103)
FunType2 0 - 255 - 1 0 Function type for analog channel 2
(IEC-60870-5-103)
InfNo2 0 - 255 - 1 0 Information number for analog channel 2
(IEC-60870-5-103)
FunType3 0 - 255 - 1 0 Function type for analog channel 3
(IEC-60870-5-103)
InfNo3 0 - 255 - 1 0 Information number for analog channel 3
(IEC-60870-5-103)
FunType4 0 - 255 - 1 0 Function type for analog channel 4
(IEC-60870-5-103)
InfNo4 0 - 255 - 1 0 Information number for analog channel 4
(IEC-60870-5-103)
Table continues on next page
Section 12 1MRK 511 287-UEN A
Monitoring
434
Technical manual
