ABB REC650 User Manual

15.3.2.2 Settings
Table 498: SETGRPS Non group settings (basic)
Name
Values (Range) Unit Step Default Description
ActiveSetGrp SettingGroup1
SettingGroup2
SettingGroup3
SettingGroup4
-
- SettingGroup1 ActiveSettingGroup
MaxNoSetGrp 1 - 4 - 1 1 Max number of setting groups 1-4
15.3.3 Parameter setting groups ACTVGRP
15.3.3.1 Identification
Function description IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Parameter setting groups ACTVGRP - -
15.3.3.2 Function block
ACTVGRP
ACTGRP1
ACTGRP2
ACTGRP3
ACTGRP4
GRP1
GRP2
GRP3
GRP4
SETCHGD
IEC09000064_en_1.vsd
IEC09000064 V1 EN
Figure 268: ACTVGRP function block
15.3.3.3 Signals
Table 499: ACTVGRP Input signals
Name
Type Default Description
ACTGRP1 BOOLEAN 0 Selects setting group 1 as active
ACTGRP2 BOOLEAN 0 Selects setting group 2 as active
ACTGRP3 BOOLEAN 0 Selects setting group 3 as active
ACTGRP4 BOOLEAN 0 Selects setting group 4 as active
Section 15 1MRK 511 287-UEN A
Basic IED functions
558
Technical manual
