ABB REC650 User Manual

Section 5 Local Human-Machine-Interface LHMI
5.1 Local HMI screen behaviour
5.1.1 Identification
Function description IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Local HMI screen behaviour SCREEN - -
5.1.2 Settings
Table 12: SCREEN Non group settings (basic)
Name Values (Range) Unit Step Default Description
DisplayTimeout 10 - 120 Min 10 60 Local HMI display timeout
ContrastLevel -100 - 100 % 10 0 Contrast level for display
DefaultScreen 0 - 0 - 1 0 Default screen
EvListSrtOrder Latest on top
Oldest on top
- - Latest on top Sort order of event list
AutoIndicationDRP Off
On
- - Off Automatic indication of disturbance report
SubstIndSLD No
Yes
- - No Substitute indication on single line
diagram
InterlockIndSLD No
Yes
- - No Interlock indication on single line diagram
BypassCommands No
Yes
- - No Enable bypass of commands
5.2 Local HMI signals
5.2.1 Identification
Function description
IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Local HMI signals LHMICTRL - -
5.2.2 Function block
1MRK 511 287-UEN A Section 5
Local Human-Machine-Interface LHMI
57
Technical manual
