ABB RED615 User Manual

Fault indication Fault code Additional information
Internal Fault
Conf. error,X110
64 Card in slot X110 is wrong type, is missing
or does not belong to the original
composition.
Internal Fault
Conf. error,X120
65 Card in slot X120 is wrong type, is missing
or does not belong to the original
composition.
Internal Fault
Conf. error,X130
66 Card in slot X130 is wrong type, is missing
or does not belong to the original
composition.
Internal Fault
Card error,X000
72 Card in slot X000 is faulty.
Internal Fault
Card error,X100
73 Card in slot X100 is faulty.
Internal Fault
Card error,X110
74 Card in slot X110 is faulty.
Internal Fault
Card error,X120
75 Card in slot X120 is faulty.
Internal Fault
Card error,X130
76 Card in slot X130 is faulty.
Internal Fault
LHMI module
79 LHMI module is faulty. The fault indication
may not be seen on the LHMI during the
fault.
Internal Fault
RAM error
80 Error in the RAM memory on the CPU
card.
Internal Fault
ROM error
81 Error in the ROM memory on the CPU
card.
Internal Fault
EEPROM error
82 Error in the EEPROM memory on the CPU
card.
Internal Fault
FPGA error
83 Error in the FPGA on the CPU card.
Internal Fault
RTC error
84 Error in the RTC on the CPU card.
7.2.2 Warnings
A fault indication message, which includes text Warning with additional text, a
code, date and time, is shown on the LHMI to indicate the fault type. If more than
one type of fault occur at the same time, indication of the latest fault appears on the
LCD. The fault indication message can be manually cleared.
When a fault appears, the fault indication message is to be recorded and stated when
ordering service.
Section 7 1MRS756499 A
Troubleshooting
80 RED615
Operation Manual
