15.7.3 Setting guidelines

The function does not have any parameters available in the local HMI or PCM600.

15.8 Single point generic control 8 signals SPC8GAPC

15.8.1 Identification

Function description IEC 61850

identification

IEC 60617

identification

ANSI/IEEE C37.2

device number

Single point generic control 8 signals SPC8GAPC - -

15.8.2 Application

The Single point generic control 8 signals (SPC8GAPC) function block is a collection

of 8 single point commands that can be used for direct commands for example reset of

LED's or putting IED in "ChangeLock" state from remote. In this way, simple

commands can be sent directly to the IED outputs, without confirmation.

Confirmation (status) of the result of the commands is supposed to be achieved by

other means, such as binary inputs and SPGAPC function blocks.

PSTO is the universal operator place selector for all control functions.

Even if PSTO can be configured to allow LOCAL or ALL operator

positions, the only functional position usable with the SPC8GAPC

function block is REMOTE.

15.8.3 Setting guidelines

The parameters for the single point generic control 8 signals (SPC8GAPC) function

are set via the local HMI or PCM600.

Operation: turning the function operation On/Off.

There are two settings for every command output (totally 8):

PulseModex: decides if the command signal for output x is Latched (steady) or

Pulsed.

tPulsex: if PulseModex is set to Pulsed, then tPulsex will set the length of the pulse (in

seconds).

Section 15 1MRK 502 071-UEN -

Control

594 Generator protection REG670 2.2 IEC and Injection equipment REX060, REX061, REX062

Application manual
