The CSV file can be opened with a spreadsheet program such as
OpenOffice.org Calc or Microsoft Excel.
5. Click Clear events to clear all events from the protection relay.
6. Click Print to print all the selected events.
4.2.12 Selecting disturbance records view
Disturbance records are listed in the disturbance records view.
• Click Disturbance records on the menu bar.
GUID-CC58DC4B-9FC9-47B0-A28A-A92B867D3009 V2 EN
Figure 52: Selecting disturbance records view
4.2.12.1 Saving disturbance records
1. Click Disturbance records on the menu bar.
2. To save the disturbance record files, click the icon in the Download Files
column of the record.
Both the disturbance record files CFG and DAT are saved at once.
GUID-0280828D-0DFF-4C83-90A0-D8E57E17E51A V2 EN
Figure 53: Saving a disturbance record
3. Open the disturbance record files with a suitable program.
Section 4 1MRS758754 B
Using the HMI
72 REC615 and RER615
Operation Manual
