Protections19 | © 2023 ABB | 1SDH001316R1002 - ECN000297030
3 - Voltage protections
List
The Voltage protections, available by default for Ekip Hi-Touch, Ekip G Touch, Ekip G-Hi Touch models and configurable in the remaining models
as additional SW package, are:
Name Type of protection
Th-
reshold
Time Additional functions
(2)
UV Minimum voltage Trip enable, Block
OV Maximum voltage
Trip enable, Block
UV2
(1)
Minimum voltage Trip enable, Block
OV2
(1)
Maximum voltage Trip enable, Block
VU Voltage unbalance
Trip enable, Block
Phase Sequence Phase sequence error
Further details about the protections are given in document 1SDH001330R1002.
(1)
protections UV2 and OV2 are not available by default with Ekip G Touch. However, they can be integrated by requesting the relative SW
package
(2)
Block configuration available via Ekip Connect
Summary table
ABB ANSI
(5)
Threshold
Tolerance
threshold
Time
Calculation
formula t
t
(3)
Tolerance t
t
(4)
UV 27
U8 = 0,5…1 Un
Step = 0,001 Un
± 2 %
(7)
t8 = 0,05...120 s
Step = 0,01 s
t
t
= t8
The best of the two values: ± 10% or ±
40 ms (for set time < 5 s) / ± 100 ms (for
set time ≥ 5 s)
OV 59
U9 = 1…1,5 Un Step
= 0,001 Un
± 2 %
(7)
t9 = 0,05…120 s
Step = 0,01 s
t
t
= t9
The best of the two values: ± 10% or ±
40 ms (for set time < 5 s) / ± 100 ms (for
set time ≥ 5 s)
UV2 27
U15 = 0,5…1 Un
Step = 0,001 Un
± 2 %
(7)
t15 = 0,05…120 s
Step = 0,01 s
t
t
= t15
The best of the two values: ± 10% or ±
40 ms (for set time < 5 s) / ± 100 ms (for
set time ≥ 5 s)
OV2 59
U16 = 1…1,5 Un
Step = 0,001 Un
± 2 %
(7)
t16 = 0,05…120 s
Step = 0,01 s
t
t
= t16
The best of the two values: ± 10% or ±
40 ms (for set time < 5 s) / ± 100 ms (for
set time ≥ 5 s)
VU
(6)
47
U14 = 2…90 % Step
= 1 %
± 5 %
t14 = 0,5…60 s
Step = 0,5 s
t
t
= t14
The best of the two values: ± 10% or ±
40 ms (for set time < 5 s) / ± 100 ms (for
set time ≥ 5 s)
Phase
Sequence
47 1-2-3 / 3-2-1
(3)
calculation of t
t
is valid for values which have exceeded the trip threshold of the protection
(4)
tolerance values valid with Trip unit supplied at full rate or by auxiliary power supply, trip time ≥ 100 ms, temperature and current values
within operating limits; the tolerance value is ± 20% if the conditions are not guaranteed
(5)
ANSI / IEEE C37-2 codification
(6)
protection not active if the higher of the voltages measured is less than 0.3 Un
(7)
the trip unit considers 3% hysteresis for quitting alarm condition

ABB SACE Emax 2 Specifications

General

Type	Air circuit breaker
Rated Current	800 A to 6300 A
Breaking Capacity	Up to 150 kA at 415 V AC
Frequency	50/60 Hz
Number of Poles	3, 4
Installation	Fixed or withdrawable
Standards	IEC 60947-2
Trip Unit	Ekip Touch, Ekip Hi-Touch
Communication	Modbus, Profibus, Ethernet
