TTH300 HEAD-MOUNT TEMPERATURE TRANSMITTER | OI/TTH300-EN REV. E 33
HART® menu levels
Process display
Configuration level
Device Setup
Device Info
Display
Process Alarm
Communication
Calibrate
Diagnosis
Process display
The process display shows the current process values.
Configuration level
The configuration level contains all the parameters required for device commissioning and configuration. The device configuration
can be changed on this level.
PROFIBUS PA® and FOUNDATION Fieldbus® H1 menu levels
Process display
Information level Configuration level
Diagnosis Device Setup
Operator Page 1 Device Info
Operator Page 2 Communication
Autoscroll Service
Signal View Display
Calibrate
Process display
The process display shows the current process values.
Information level
The information level contains the parameters and information that are relevant for the operator.
The device configuration cannot be changed on this level.
Configuration level
The configuration level contains all the parameters required for device commissioning and configuration. The device configuration
can be changed on this level.
Change from one to tw o columns

ABB TTH300 Series Specifications

General

Type	Temperature transmitter
Display	Optional LCD display
Input	RTD, Thermocouple, Resistance
Output	4-20 mA, HART
Accuracy	±0.1% of span
Ambient temperature	-40°C to +85°C (-40°F to +185°F)
Housing material	Aluminum, Stainless steel
Communication	HART
Configuration	Via HART protocol, configuration tools
Power supply	10.5 ... 45 V DC (depending on version and load)
Measurement Range	Depends on sensor type (RTD, Thermocouple, etc.)
Protection Rating	IP66
Sensor Type	RTD, Thermocouple
