8
LCD Monitor General Specification
19 “ active matrix color TFT LCD
Panel type
AU M190EN04
Display size
376.32mm (H) × 301.06mm(V)
VGA 640 × 480 (60/75 Hz)
SVGA 800 × 600 (60/75 Hz)
XGA 1024 × 768 (60/70/75 Hz)
Display mode
SXGA 1280 × 1024 (60/75 Hz)
Pixel pitch
0.294mm(H) × 0.294mm(V)
Display dot
1280 x (RGB) × 1024
Pixel clock
135MHz(max.)
Contrast ratio
550:1(typ.)
Brightness
270 cd/m
2
(typ.)
Response time (Tr+Tf)
8ms(Typ.)
Display color
16.2M(6-bits+FRC)
Viewing angle
H: 140 / V: 135 (typ.)
Pc interface
RGB Analog Interface
Signal connector
D-Sub 15pin
Horizontal Frequency 30KHz ----80KHz
Interface frequency
Vertical Frequency 55Hz ------75Hz
Plug & play
VESA DDC2B
Power Input voltage
47-63HZ, 100 VAC to 264VAC ±10%
Total output power
60Watt(max.)
