6 Chapter 1
ITEM DESCRIPTION ITEM DESCRIPTION
JP1/JP2 LVDS CONN. JP26 LINE IN CONN.
JP3/17/31 FAN CONN. JP27 DDR SO-DIMM0 CONN.
JP5 BLUETOOTH CONN. JP28 PCMCIA CONN.
JP6 LCM CONN. JP29 MINI-PCI CONN.
JP7 CARD READER CONN. JP30 ODD CONN.
JP8 TOUCH-PAD CONN. JP32 HDD CONN.
JP9 KEYBOARD CONN. JP33 TV-TUNER CONN.
JP11 SPEAKER CONN. PCN1 AC-IN CONN
JP12 SUBWOOFER CONN. PCN2 BATTERY CONN.
JP13 CRT CONN. SW1 LID SWITCH
JP14 TV-OUT CONN. SW2 E-MAIL BTN
JP15 RJ-11/RJ-45 CONN. SW3 USER BTN1
JP16/18/19/21 USB CONN. SW4 USER BTN2
JP20 CPU SOCKET SW5 INTERNET BTN
JP22 MDC CONN. U35 NORTH BRIDGE
JP23 1394 CONN. U21 SOUTH BRIDGE
JP24 LINE OUT CONN. U39 VGA CHIP
JP25 DDR SO-DIMM1 CONN.
