Chapter 3 Aspire 1800
5. Remove the one screw.
6. Then detach the invertor board from the LCD panel module.
7. Remove the one screw on each bracket to release the bracket from the LCD module.
8. Take the entire LCD panel out from the top cover.
9. Remove the four screws to detach the bracket.
10. Then take the LCD bracket from the panel.
11. Remove another four screws to release the bracket.
12. Then detach the bracket out from the LCD Panel.
13. Tear the tapes as video guides you from the LCD wire set cable and disconnect it from the panel.
