Hardware Specifications and Configurations 1-37
Bluetooth Interface
Bluetooth Module
Item Specifications
Chipset Atheros AR3011 Broadcom BCM2070
Data throughput TX 1.2 Mbits/sec, RX 1.2 Mbits/sec
Protocol Bluetooth 2.1+EDR, Bluetooth 3.0+HS
Interface USB 2.0
Connector type 8 pin narrow pitch connector JST SM06B-XSRK-E-TB
Supported protocol
2.1, 3.0
Item Specifications
Controller AR3011
Feature
Single-chip Bluetooth 2.1+EDR and 3.0+HS integrated solution
USB 2.0 full-speed device interface with support for Device
Firmware Upgrade (DFU)
SPI interface supports external serial flash devices
Two on-chip 1.2V linear voltage regulators
Integrated 32-bit CPU with 32KB data RAM and 256KB program
RAM
On-board PLL
On-chip low power oscillator (LPO)
WLAN coexistence interface
Standard USB HCI interface
Controller BCM2070
Feature
Single-chip Bluetooth 3.0 HCI solution
Point-to-multipoint operation
External USB interface for data
Onboard antenna and SMA RF connector
Built-in power amplifier
Coexistence support
