2-22 System Utilities
Using LAN EEPROM Utility 0
Use EEPROM.BAT to write data to LAN EEPROM under DOS mode.
1. In DOS mode, navigate to 57780_HMA51CP folder (Figure 2-23).
Figure 2-22. Updating EEPROM
2. Run EEPROM.BAT to automatically modify data in LAN EEPROM. (Figure 2-23)
Figure 2-23. Updating EEPROM
3. Reboot computer when process has completed.
C:\>57780_HMA51CP>eeprom.bat
Start to program image into UTP ...
52 bytes was done.
File Name : Q5WP2N.bin
File Size : 96
Offset : 0x0000
Bytes Read : 96
Checking selfboot file Content........: passed
Checking selfbootII OTP Content.......: passed
Comparing OTP to Q5WP2N.bin...........: passed
Checking Bond Id......................: passed
Firmware Version......................: sb2 2.05
Mac Address...........................: 00201805221F
Group A. Register Tests
A1. Indirect Register Test
