01 Product Specification
1.
General:
Acer B243HL is designed with LVDS interface and VGA/DVI-D input, it featured with embedded
universal AC power supplies and audio input. It’s a green product and meets all ROHS standard. The
power button and display control buttons are on the front of the monitor. The monitors shall
automatically to display lower resolution video modes into 1920x1080 full screen display. The image
can be adjusted through OSD control. It support HDCP and color management function.
1.1 Main Features
1.1.1 For AUO M240HW01-V0 panel
Maximum resolution : 1920(x3) x 1080 @ 60Hz
Back light system : 2 bar Led
Pixel pitch : 276.75 um (H) x 276.75 um (V)
Display area : 531.36mm (H) x 298.89mm (V)
Brightness : 250cd/m² (TYP.)
Contrast ratio : 1000׃1 (TYP.)
ACM :80000:1 (Max)
Response time (Tr+Tf) : 5ms (TYP. ON/OFF)
Viewing angle : 170° (H)/ 160°(V), (TYP.)
Input interface : Analog (D-sub 15 pin)
Digital Option (DVI-D 24 pin )
Power management : Compatible with VESA DPMS
Plug & Play : VESA DDCCI
OSD language : English, French, Spanish, Italian, Deutsch,
Simplified Chinese, Traditional Chinese, Japanese
(Dutch, Finnish, Russian depend on sale region)
Universal AC power supply
1.1.2 Other main function features
z Input interface : VGA/DVI/USB upstream
z VGA input : D-Sub
z DVI input : DVI-D
z USB : Support USB2.0 (optional function)
1.2 Accessories
AC Power Cord : 1.8 m. (Black. Cord type depend on sale region)
VGA cable : 1.8 m. (15 pin D-SUB, black cable with blue male connector)
User manual : English (640Mb CD)
DVI cable (option) : 1.8 m. (18+1 pin, black cable with white connector)

Acer B243HL Specifications

General

Pixel pitch	0.276 x 0.276 mm
Display diagonal	24 \
Vertical scan range	55 - 75 Hz
Viewable size diagonal	610 mm
Contrast ratio (dynamic)	8000000:1
Contrast ratio (typical)	1000:1
Viewing angle, horizontal	176 °
Display brightness (typical)	250 cd/m²
Display viewable area (HxV)	531 x 299 mm
Mean time between failures (MTBF)	50000 h
HDCP	Yes
DVI-D ports quantity	0
Product color	Black
Market positioning	-
Tilt angle range	-5 - 15 °
Height adjustment	110 mm
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
Sustainability certificates	ENERGY STAR
Cables included	DVI, VGA

Weight and Dimensions

Depth (without stand)	235 mm
Width (without stand)	567 mm
Height (without stand)	393 mm
Weight (without stand)	7600 g
