1. The front panel indicators are visible even when the computer cover is closed
up.
2 Microphone Internal microphone for sound recording.
3 Display screen Also called Liquid-Crystal Display (LCD),
displays computer output
(Configuration may vary by models).
4 HDD Indicates when the hard disk drive is
active.
Num Lock Lights up when Num Lock is activated.
Caps Lock Lights up when Caps Lock is activated.
5 Keyboard For entering data into your computer.
6 Touchpad Touch-sensitive pointing device which
functions like a computer mouse.
7 Click buttons (left
and right)
The left and right buttons function like
the left and right mouse buttons.
8 Communication
indicator
Indicates the status of WLAN / 3G
communication. (only for certain models)
Power
1
Indicates the computer's power status.
Battery
1
Indicates the computer's battery status.
1. Charging: The light shows amber when
the battery is charging.
2. Fully charged: The light shows blue
when in AC mode.
Bluetooth
communication
indicator
Indicates the status of Bluetooth
communication. (only for certain models)
9 Palmrest Comfortable support area for your hands
when you use the computer.
10 Power button /
indicator
Turns the computer on and off. /
Indicates the computer's power status.
# Icon Item Description
