14
Main Board Diagram
Scalar IC NT68665MFG-128
(Include MCU ,ADC,flash rom OSD)
(U203)
D-Sub
Connector
(CN101)
H sync
V sync
RGB
LCD Interface
(CN402)
Key Board
Control
CN407
Crystal
(X201)
12MHz
DVI
Connector
(CN102)
EEPROM
M24C16
(U204)
