3.2 Jumper Settings
The following table lists the possible jumper settings:
Table 1 Jumper Settings
Jumper Setting Function
JP1 1-2
*
2-3
VGA Interrupt
Disabled
Enabled
JP2 1-2
2-3
*
Wake-on LAN
Active low
Active high
JP4 1-2, 4-5
2-3, 5-6
*
Audio Line-in Source
AMC connector
Line-in connector
JPX1 1-2
2-3
*
CPU Type
AMD K6S-300
Other CPUs
SW1 Settings
B1 On
Off
*
Hardware Monitor
Enabled
Disabled
Bus Frequency (MHz)
CY2283-1
B2 B3 B4 CPU AGP PCI
Clk. Clk. Clk.
Off On Off 66 66 33
Off Off Off 75 60 30
On On Off 83 66 33
On
*
Off
*
Off
*
100 66 33
ICS9148-16
B2 B3 B4 CPU AGP PCI
Clk. Clk. Clk.
Off On On 66 66 33
On On Off 75 60 30
Off On Off 83 66 33
Off Off Off 100 66 33
*
Default setting
