Acer X193W User Manual

9
LCD Monitor General Specification
Driving system TFT Color LCD
Active Display Area 408.24(H) × 255.15mm(V)
Pixel pitch 0.2835 x 0.2835
Contrast Ratio 1000 : 1
LCD Panel
Response time 5ms
Separate Sync. H/V TTL
H-Frequency 30kHz – 80kHz
Input
V-Frequency 55-75Hz
Viewing angle 90∘ H and V
Display Colors 16.7M (Hi-FRC)
Max. Dot Clock 140MHz
Display mode 1400 × 900 @60Hz
ON Mode < 45W
EPA ENERGY STAR
®
OFF Mode < 1W
Contrast control
Set to factory preset value, which allows that the brightest two of 32 linear distributed
gray-scales (0～ 700mv) can be distinguished.
Power Source 90~240VAC,47~63Hz
Environmental
Considerations
Operating Temp: 0° to 40°C
Storage Temp: -20° to 60°C
Operating Humidity: 15% to 90%
Storage Humidity: 15% to 90%
Main Dimension(monitor)
359(W)×164 (H)×454(D) mm
Leakage current < 3.5MA
Peak surge current < 55 A peak at 240 VAC and cold starting

Acer X193W Specifications

General

Pixel pitch	0.284 mm
Display diagonal	19 \
Display resolution	1440 x 900 pixels
Vertical scan range	56 - 60 Hz
Horizontal scan range	24 - 80 kHz
Viewable size, vertical	255 mm
Contrast ratio (typical)	2000:1
Viewable size, horizontal	408 mm
Viewing angle, horizontal	160 °
Display brightness (typical)	300 cd/m²
Certification	UL, CUL, TUV/GS, T-Mark, ISO9241-3/-7/-8, FCC/B, VCCI, CE, C-tick, BSMI, WHQL, ISO 13402-6
Product color	Black
Market positioning	-
Cable lock slot	Yes
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
Power requirements	100 - 240 VAC, 50 - 60 Hz
Power consumption (off)	1 W
Power consumption (standby)	2 W
Power consumption (typical)	37 W

Weight and Dimensions

Depth (with stand)	163.7 mm
Width (with stand)	454.3 mm
Height (with stand)	359.2 mm
Weight (without stand)	4400 g
