Alfano 7 User Manual

Engine rpm
Speed
T2 exhaust
T1 water
Minimum
8869 RPM
52.9 km/h
265 °C
55 °C
Maximum
15271 RPM
134.0 km/h
592 °C
59 °C
EXAMPLE
During the session of 07/19/2023 which started at
8.09 pm the maximum values recorded are:
15653
134.0
594
60
RPM
km/h
°C
°C
Engine rpm
Speed
Exhaust gas temperature
Water temperature
Taking into consideration the third fastest lap, i.e. the fourth lap completed with a time of
51.95 seconds, the maximum and minimum values recorded are:
Data analysis page two is divided into two
parts:
The upper part provides a summary of the
maximum values of the entire session for:
RPM
Speed
Exhaust T2
Water T1
The bottom section summarizes the 3 best
laps showing:
Corresponding lap number
Lap time
Min e max RPM
Min and max Speed
Min and max Exhaust temperature T2
Min and max Water temperature T1
Second Page
79
10. Data Analysis Directly from the Alfano 7
