Assembly data
Production Line
Xone
Product
PX5
Assembly Stage
Final assembly
Issue Date
12/07/16
Revision Number
ISSUE 1
AH-M0773
4. INSPECT FOR DEFECTS AA10185 CHASSIS XONE: PX5 U SIDE.
5. FIT THE REAR PANEL TO THE CHASSIS U SIDE AND SECURE USING AB9037 SCREW
M3X5 TRUNC CSK TORX x4.
