Publication 1769-UM009B-EN-P - May 2002
A-2 Specifications
Electrical and DeviceNet
Specifications
Electrical /EMC: The module has passed testing at the following levels:
ESD Immunity (IEC61000-4-2) • 4kV contact, 8kV air, 4kV indirect
Radiated Immunity
(IEC61000-4-3)
• 10 V/m, 80 to 1000 MHz, 80% amplitude
modulation, +900 MHz keyed carrier
Fast Transient Burst
(IEC61000-4-4)
• 2 kV, 5 kHz
Surge Immunity
(IEC61000-4-5)
• 2 kV galvanic gun
Conducted Immunity
(IEC61000-4-6)
• 10V, 0.15 to 80 MHz
(2)
(1)
For operation above 2000 meters, consult the factory.
(2)
Conducted Immunity frequency range may be 150 kHz to 30 MHz if the Radiated Immunity frequency range is 30
MHz to 1000 MHz.
Specification Value
Specification Value
Bus Current Draw (maximum) 440 mA at 5V dc (2.2 Watts)
DeviceNet Power Requirements N.E.C. Class 2
90 mA at 11V dc (maximum)
110 mA at 25V dc (maximum)
200 mA for 1.5 ms (inrush)
Heat Dissipation (maximum) 3.8 Watts (assumes typical DeviceNet network traffic)
Baud Rates 125K bits/second (default)
250K bits/second
500K bits/second
Maximum Cable Length 500 meters at 125K baud
100 meters at 500K baud
DeviceNet Cable Allen-Bradley catalog number 1485C-P1-Cxxx. Refer to
publication DN-2.5 for more information.
Power Supply Distance Rating 4 (The module may not be more than 4 modules away
from the power supply).
DeviceNet to Compact Bus
Isolation
Verified by one of the following dielectric tests: 500V ac
for 1 minute or 707V dc for 1 minute.
30V dc working voltage (IEC Class 2 reinforced
insulation)
Vendor I.D. code 1
Product Type Code 12
Product Code 105
