Allen-Bradley 22C-D045A103 User Manual

62 Rockwell Automation Publication 22C-UM001J-EN-E - January 2017
Chapter 3 Programming and Parameters
P036 [Start Source] Related Parameter(s): P037
, P042, A166, d301
Stop drive before changing this parameter.
Sets the control scheme used to start the drive when in Auto/Remote mode.
Refer to Start and Speed Reference Control on page 37 for details about how other drive settings can override the setting of this parameter.
Options 0 “Keypad” Integral keypad controls drive operation.
• I/O Terminal 01 = Stop: Coast to Stop
• I/O Terminal 02 = Not Used
• I/O Terminal 03 = Not Used
1 “3-Wire” I/O Terminal Block controls drive operation.
• I/O Terminal 01 = Stop: Per P037
[Stop Mode]
• I/O Terminal 02 = Start
• I/O Terminal 03 = Direction
2 “2-Wire” I/O Terminal Block controls drive operation.
• I/O Terminal 01 = Stop: Coast to Stop
• I/O Terminal 02 = Run FWD
• I/O Terminal 03 = Run REV
3 “2-W Lvl Sens” (Default) I/O Terminal Block controls drive operation.
• I/O Terminal 01 = Stop: Coast to Stop
• I/O Terminal 02 = Run FWD
• I/O Terminal 03 = Run REV
Drive will restart after a “Stop” command when:
• Stop is removed and Run FWD is held active
4 “2-W Hi Speed” I/O Terminal Block controls drive operation.
• I/O Terminal 01 = Stop: Coast to Stop
• I/O Terminal 02 = Run FWD
• I/O Terminal 03 = Run REV
Outputs are kept in a ready-to-run state. The drive will respond to a “Start” command within 10 ms.
5 “Comm Port” Remote communications controls drive operation.
• I/O Terminal 01 = Stop: Coast to Stop
• I/O Terminal 02 = Not Used
• I/O Terminal 03 = Not Used
6 “2-W Lvl/Enbl” I/O Terminal Block controls drive operation.
• I/O Terminal 01 = Function Loss: Fault and Coast to Stop
• I/O Terminal 02 = Run FWD
• I/O Terminal 03 = SW Enable
Drive will restart after a “Stop” command when:
• Stop is removed and Run FWD is held active
IMPORTANT
For all settings except options 3 and 6, the drive must receive a leading edge from the start input for the drive to start after a stop input, loss of power or
fault condition.
ATTENTION: Hazard of injury exists due to unintended operation. When P036 [Start Source] is set to
option 3 or option 6, and the Run input is maintained, the Run inputs do not need to be toggled after a
Stop input or a fault clear for the drive to run again. The drive will stop only when the stop command is
maintained or the drive is faulted.
ATTENTION: When operating in 2-Wire Level Sense (Run Level), the drive should only be controlled from
the Digital Input Terminal Blocks. This should NOT be used with any other DSI or Network device.
IMPORTANT
There is greater potential voltage on the output terminals when using this option.
ATTENTION: Hazard of injury exists due to unintended operation. When P036 [Start Source] is set to
option 3 or option 6, and the Run input is maintained, the Run inputs do not need to be toggled after a
Stop input or a fault clear for the drive to run again. The drive will stop only when the stop command is
maintained or the drive is faulted.
