Publication 1756-UM001G-EN-P - January 2007
88 Configure PhaseManager
Minimum System
Requirements
To develop PhaseManager programs, you need:
• a ControlLogix controller, firmware revision 16.0 or later.
• a communication path to the controller.
• RSLogix 5000 software, version 16.0 or later.
To enable PhaseManager support, you need the full or professional
editions of RSLogix 5000 programming software or RSLogix 5000 with
PhaseManager software (9324-RLDPMENE).
Equipment Phase
Instructions
The controller supports several equipment-phase ladder diagram (LD)
and structured text (ST) instructions.
PhaseManager Instructions
Instruction Instruction Function
PSC Signal a phase that the state routine is complete and to
proceed to the next state.
PCMD Change the state or substate of a phase.
PFL Signal a failure for a phase.
PCLF Clear the failure code of a phase.
PXRQ Initiate communication with RSBizWare Batch software.
PRNP Clear the NewInputParameters bit of a phase.
PPD Set up breakpoints within the logic of a phase.
PATT Take ownership of a phase to either:
• prevent another program or RSBizWare Batch software
from commanding a phase.
• make sure another program or RSBizWare Batch software
does not already own a phase.
PDET Relinquish ownership of a phase.
POVR Override a command.
