Allen-Bradley FLEX I/O DeviceNet 1794-ADN User Manual

18 Rockwell Automation Publication 1794-IN099D-EN-P - November 2018
FLEX I/O DeviceNet Adapter Module
Environmental
Attribute Value
Operating temperature
IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock):
-20…+70 °C (-4…+158 °F)
Temperature, surrounding air,
max.
70 °C (158 °F)
Nonoperating temperature
IEC 60068-2-1 (Test Ab, Unpackaged nonoperating Cold),
IEC 60068-2-2 (Test Bb, Unpackaged nonoperating Dry Heat),
IEC 60068-2-14 (Test Na, Unpackaged nonoperating Thermal Shock):
-40…85 °C (-40…185 °F)
Relative humidity
IEC 60068-2-30 (Test Db, Unpackaged Damp Heat): 5…95%
noncondensing
Vibration IEC 60068-2-6 (Test Fc, Operating): 5 g @ 10…500 Hz
Operating shock IEC 60068-2-27 (Test Ea, Unpackaged Shock): 30 g
Nonoperating shock IEC 60068-2-27 (Test Ea, Unpackaged Shock): 50 g
Emissions IEC 61000-6-4
ESD immunity
IEC 61000-4-2:
6 kV contact discharges
8 kV air discharges
Radiated RF immunity
IEC 61000-4-3:
10V/m with 1 kHz sine-wave 80% AM from 80…2000 MHz
10V/m with 200 Hz 50% Pulse 100% AM at 900 MHz
10V/m with 200 Hz 50% Pulse 100% AM at 1890 MHz
3V/m with 1 kHz sine-wave 80% AM from 2000…2700 MHz
EFT/B immunity
IEC 61000-4-4:
±2 kV at 5 kHz on power ports
±4 kV at 5 kHz on communications ports
Surge transient immunity
IEC 61000-4-5:
±1 kV line-line (DM) and ±2 kV line-earth (CM) on power ports
±2 kV line-earth (CM) on communications ports
Conducted RF immunity
IEC 61000-4-6:
10V rms with 1 kHz sine-wave 80% AM from 150 kHz…80 MHz
