AOC 917SW User Manual

19" LCD Color Monitor AOC 917Sw
44
C417 065G0402104 15 MLCC 0402 0.1UF K 16V X5R
C416 065G0402104 15 MLCC 0402 0.1UF K 16V X5R
C415 065G0402104 15 MLCC 0402 0.1UF K 16V X5R
C414 065G0402104 15 MLCC 0402 0.1UF K 16V X5R
C413 065G0402104 15 MLCC 0402 0.1UF K 16V X5R
C409 065G0402104 15 MLCC 0402 0.1UF K 16V X5R
C407 065G0402104 15 MLCC 0402 0.1UF K 16V X5R
C406 065G0402104 15 MLCC 0402 0.1UF K 16V X5R
C404 065G0402104 15 MLCC 0402 0.1UF K 16V X5R
C403 065G0402104 15 MLCC 0402 0.1UF K 16V X5R
C401 065G0402104 15 MLCC 0402 0.1UF K 16V X5R
C412 065G0402220 31 CHIP 22PF 50V NPO
C411 065G0402220 31 CHIP 22PF 50V NPO
C103 065G0402220 31 CHIP 22PF 50V NPO
C102 065G0402220 31 CHIP 22PF 50V NPO
C408 065G0402224 17 CAP CER 0.22UF -20%-80%
C113 065G0402473 12 CHIP 0.047UF 16V X7R
C110 065G0402473 12 CHIP 0.047UF 16V X7R
C109 065G0402473 12 CHIP 0.047UF 16V X7R
C107 065G0402473 12 CHIP 0.047UF 16V X7R
C106 065G0402473 12 CHIP 0.047UF 16V X7R
C105 065G0402473 12 CHIP 0.047UF 16V X7R
C101 065G0402473 12 CHIP 0.047UF 16V X7R
C104 065G0402509 31 CHIP 5PF 50V NPO
C108 065G0402509 31 CHIP 5PF 50V NPO
C111 065G0402509 31 CHIP 5PF 50V NPO
FB402 071G 56K121 M CHIP BEAD
FB401 071G 56V301 B CHIP BEAD FCM2012VF-301T07 BULLWILL
FB101 071G 59K190 B 19 OHM BEAD
FB102 071G 59K190 B 19 OHM BEAD
FB103 071G 59K190 B 19 OHM BEAD
D401 093G 64 33 DIO SIG SM BAV99 (PHSE)R
ZD103 093G 39S 34 T UDZSNP5.6B ROHM
ZD104 093G 39S 34 T UDZSNP5.6B ROHM
D402 093G3004 3 SM340A
715G2904 1 MAIN PCB 57X64X1.6MM DS
Q404 057G 417517 TRA LMBT3906LT1G -200MA/-40V SOT-23 LRC
U404 056G 563916 IC LD1117DT33TR DPAK
709G2904 QS001 CONSUMPTIVE ASS'Y
052G 2191 A PAPER TAPE

AOC 917SW Specifications

General

Pixel pitch	0.2835 x 0.2835 mm
Aspect ratio	16:10
Display diagonal	19 \
Display resolution	1440 x 900 pixels
Vertical scan range	56 - 75 Hz
Horizontal scan range	30 - 60 kHz
Viewable size, vertical	255 mm
Contrast ratio (typical)	3000:1
Viewable size, horizontal	408 mm
Viewing angle, horizontal	160 °
Display brightness (typical)	300 cd/m²
Certification	cUL, FCC, CE, TUV-S, EPA, ISO13406-2, RoHS, GOST, Pixel Fault Class II
Product color	Black
Market positioning	-
Compliance industry standards	DDC 1/2B/CI
Power requirements	110-240VAC 50/60Hz
Plug and Play	Yes
LED indicators	Stand-by
Tilt angle range	-5 - 20 °
Panel mounting interface	100 x 100 mm
Power consumption (standby)	1 W
Power consumption (typical)	36 W
Package weight	4700 g

Weight and Dimensions

Depth (with stand)	204 mm
Width (with stand)	439 mm
Height (with stand)	358 mm
Weight (without stand)	3800 g
