AOC e2060Swd User Manual

52
Panel
Model
name
E2260P
HU
/E2260
S
HU
/
E2260P
DA
/E2260S
DA
/E2260S
D
Driving system
TFT Color LCD
Viewable Image Size
5
5.86 cm
diago
nal
Pixel pitch
0.282mm(H) x 0.282mm(V)
Video
(
E2260P
HU
/E2260S
HU
)
R, G, B Analog lnterface & Digital Interface & HDMI lnterface
Video
(E2260PDA/E2260SDA/E2260SD)
R, G, B Analog lnterface & Digital Interface
Separate Sync.
H/V TTL
Display Color
16.7M Colors
Dot Clock
146
MHz
Resolution Horizontal scan range 30 kHz - 83 kHz
Horizontal scan Size(Maximum)
473.76mm
Vertical scan range 50Hz - 76 Hz
Vertical scan Size(Maximum) 296.1mm
Optimal preset resolution 1680 x 1050@60Hz
Plug & Play VESA DDC2B/CI
Input connector
(E2260PHU/E2260SHU)
D-Sub 15pin DVI 24pin，HDMI
Input connector
(E2260PDA/E2260SDA/E2260SD)
D-Sub 15pin DVI 24pin
Input Video Signal Analog: 0.7Vp-p(standard), 75 OHM, TMDS
Power Source 100-240V~, 50/60Hz
Power Consumption
Active
:
38
W
(
typical
)
Standby <
0.5
W
Off timer
0
-
24 hrs
Speakers(E2260PDA/E2260SDA
E2260PHU/E2260SHU)
2W x 2
Physical
Characteristics
Connector type
(E2260PHU/E2260SHU)
15-pin Mini D-Sub DVI-D,HDMI
Connector type
(E2260PDA/E2260SDA/E2260SD)
15-pin Mini D-Sub DVI-D
Signal Cable Type Detachable
Environmental
Temperature:
Operating 0° to 40°
Non-Operating -25°to 55°
Humidity:
Operating 10% to 85% (non-condensing)
Non-Operating 5% to 93% (non-condensing)

AOC e2060Swd Specifications

General

Color	black
Tiltable	yes
Touch Screen	no
OS Compatibility	mac, windows
Screen Size	19.5 inches
Aspect Ratio	16:9
Resolution	1600 x 900
Refresh Rate	60hz
Response Time	5 milliseconds
Brightness	200 candela per square meter
Contrast Ratio	20, 000, 000:1
Horizontal Scan Rate	83 kilohertz
Built-In Speakers	no
Power Consumption	25 watts
Width with Stand	18.8 inches
Net Weight without Stand	6.1 pounds
