AOC E2251FWU Service Manual

30
A34G2713AEDA1B0130 BEZEL
Q40G000461544A POP LABEL FOR E2251FWU
Q40G000461547A DC-5V LABEL
Q41G78S161570A E2251FWU QUICK SETUP GUIDE
Q44GB11961501A00JM ARTWORK CARTON
Q45G8801607 7 P.E. BAGX200X140X0.04
Q45G9901609273 N P.E. BAGX500X630X0.3
E05201 Q52G1001209 A JY AL FOIL
Q52G1001211 B JY AL FOIL
Q52G1001211598 JY AL FOIL
Q52G1001MNT010AFJY AL FOIL
Q52G1501526 B XW TAPE_DOUBLE
ECN803 S95G176T006H29 FFC CABLE 6PIN P1.0 340MM 2nd Source
089F815034006L
1.0*6P 340MM 同向 3.5/5 3.5/10 镀金
ECN405 S95G80183K08 HARNESS 30P-30P(A2004) 300MM
095F210B003K08 3K08 HALB
Q41G78D1615 9A WARRANTY CARD
Q45G2010M0201A P.E. BAG (INSTR. BOOK)
Q70G22C161530B E2251FWU CD MANUAL
040G 58162435A PN LABEL FOR MANUAL PE BAG
Q26G 800504 2B BARCODE LABEL FOR 3
Q40G000161515A CARTON LABEL
Q40G022N615B17 RATING LABEL AP/HK/ANZ/CN
C815 067G315M1007KV EC 10UF 20% 50V 8*7
C704 067G315M1514KV EC 150UF 20% 25V 8*7
C810 067G315M1514KV EC 150UF 20% 25V 8*7
C811 067G315M1514KV EC 150UF 20% 25V 8*7
CN701 088G 304 11 C DC POWER JACK 3P 2.5MM
CN702 088G 352 11VCL USB CONN A TYPE V/T 4P BLACK H=13.74
X401 093G 2251B J CRYSTAL 12MHZ NXS12.000AC30F-KAB10
CN401 311GW200A03ABX WAFER 2.0MM 3P
CN405 311GW200C30ABL WAFER 2.0MM 2*15P
C470 067G305M1013CB EC 100UF 20% 16V 6.3*7
C701 067G305M1013CB EC 100UF 20% 16V 6.3*7
C752 067G305M1013CB EC 100UF 20% 16V 6.3*7
C754 067G305M1013CB EC 100UF 20% 16V 6.3*7
C756 067G305M1013CB EC 100UF 20% 16V 6.3*7
FB701 071G 55 26 S BEAD 3.5*6MM 127R 25% LB3.5¡Á0.8¡Á6-2
FB702 071G 55 26 S BEAD 3.5*6MM 127R 25% LB3.5¡Á0.8¡Á6-2
U702 056G 379110 IC G5126TB1U SOT23-6
