180
319
120 120
150
67 67 65 65
200
I
200
50 50
450
Overview
Boiler dimensions
Legend
1. Metal flue gas connection 2. Shock
absorber 3. Flame / ignition electrode
4. Heating flow probe 5. Manual purge 6.
Secondary plate heat exchanger 7. Siphon
8. Safety valve 3 bar 9. Flowmeter c.
Sanitary 10. Filling valve 11. Heating circuit
filter 12. Recirculation pump with vent valve
13. Motorized 3-way valve 14. Minimum
load pressure switch 15. Heating return
probe 16. Main plate 17. Burner 18. Valve
gas 19. Fan 20. Outlets for flue gas
analysis (smoke)
A. Installation Tour
Place the boiler in accordance with the technical rules, using a bubble level.
The legend
Minimum distances for installation In order to
allow easy maintenance (overhaul) of the boiler, it is necessary to observe the
minimum distances indicated in the diagram.
B. Hot water outlet C.
Gas inlet D. Cold water
inlet E. Installation return
PRODUCT DESCRIPTION
745 25 745 0 0 3 0 5 3 28
12
18
1
17
11
20
16
10
15
2
6
9
5
4
19
14
3
7
13
8
/ 7
