CONTENTS
FEATURES .................................................................................................................................... 3
KEYPAD INSTALLATION ........................................................................................................... 4-5
WIRING SPECIFICATIONS ...........................................................................................................5
POWERING UP PANEL ................................................................................................................. 6
HOW TO PROGRAMME ................................................................................................................7
PROGRAMMING MAP ................................................................................................................... 8
PROGRAMMING FUNCTIONS ................................................................................................... 11
PERIDIAX FEATURE ................................................................................................................... 19
PROGRAMMING TEXT ............................................................................................................... 20
RETURNING TO FACTORY DEFAULT ...................................................................................... 21
QUICK CODES ............................................................................................................................ 21
ZONE WIRING OPTIONS ............................................................................................................ 22
WIRING OF SIRENS .................................................................................................................... 23
WIRING OF OUTPUTS
RELAYS ........................................................................................................................... 24
DIGITAL COMMUNICATORS ......................................................................................... 24
FIRE DETECTORS ......................................................................................................... 24
LIST WITH SHORT CODES ........................................................................................................ 25
DEFAULT CHART ........................................................................................................................ 26
PROBLEM SOLVING ................................................................................................................... 27
TECHNICAL SPECIFICATION .................................................................................................... 29
MAIN PANEL WIRING DIAGRAM ............................................................................................... 30
FEATURES
The CS350 is a microcomputer based alarm control panel operating from remote keypads, and has
the following features:
l Facility for up to 4 CD3008 remote keypads... one CD3008 is supplied with the panel.
l 6 freely programmable dual zones.
l Auxiliary tamper input.
l Supervised bell tamper input.
l Digital communicator fault input... reprogrammable to include remote engineer reset.
l New perimeter system capability which provides local alarms for perimeter zone activations.
This can reduce false alarms considerably. Exremely useful with inertia shock sensors.
l 4 freely programmable open collector outputs.
l 2 freely programmable high current outputs (eg. to control sirens).
l LCD with freely programmable zone names... up to 12 characters.
l Battery input monitored.
l Four user codes.
See Programming Functions on page 14 for zone (Input) and page 15 for output types.
