No. Description
1 ATX 12V Power Connector (ATX12V3)
2 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1, Blue)*
3 PSU SMBus Header (PSU_SMB1)
4 ATX Power Connector (ATXPWR1)
5 System Fan Connector (4-pin) (FAN3)
6 System Fan Connector (6-pin) (FAN4)
7 System Fan Connector (6-pin) (FAN5)
8 2 x 288-pin DDR4 DIMM Slots (DDR4_A2, DDR4_B2, White)*
9 System Fan Connector (6-pin) (FAN6)
10 SATA DOM Power Connector (SATAPWR1)
11 AM4 PGA 1331 Socket
12 M.2 Socket (M2_2) (Type 2242 / 2260 / 2280)
13 SATA3 DOM Connector (SATA_0), Red
14 USB 3.2 Gen1 Header (USB3_3_4)
15 SATA3 Connector (SATA_1)
16 M.2 Socket (M2_1) (Type 2242 / 2260 / 2280 / 22110)
17 SATA3 Connector (SATA_3)(Upper), SATA3 Connector (SATA_2)(Lower)
18 TPM-SPI Header (TPM_BIOS_PH1)
19 SATA3 Connector (SATA_5)(Upper), SATA3 Connector (SATA_4)(Lower)
20 SATA3 Connector (SATA_7)
21 SATA3 Connector (SATA_6)
22 ermal Sensor Header (TR1)
23 System Panel Header (PANEL1)
24 Auxiliary Panel Header (AUX_PANEL1)
25 Clear CMOS Pad (CLRMOS1)
26 System Fan Connector (4-pin) (FAN1)
27 System Fan Connector (4-pin) (FAN2)
28 TPM Header (TPM1)
29 Chassis ID1 Jumper (CHASSIS_ID1)
(Reserved for BOM option)
30 Speaker Header (SPEAKER1)
31 BMC SMBus Header (BMC_SMB_1)
32 Intelligent Platform Management Bus Header (IPMB_1)
33 Chassis ID2 Jumper (CHASSIS_ID2)
(Reserved for BOM option)
