Asus A52F User Manual

14
Notebook PC User Manual
10
LAN Port
The RJ-45 LAN port with eight pins is larger than the RJ-11
modem port and supports a standard Ethernet cable for
connection to a local network. The built-in connector
allows convenient use without additional adapters.
Kensington® Lock Port
The Kensington® lock port allows the Notebook PC to
be secured using Kensington® compatible Notebook PC
security products. These security products usually include
a metal cable and lock that prevent the Notebook PC to
be removed from a xed object. Some may also include a
motion detector to sound an alarm when moved.
HDMI
HDMI Port
HDMI (High-Denition Multimedia Interface) is an
uncompressed all-digital audio/video interface between
any audio/video source, such as a set-top box, DVD player,
and A/V receiver and an audio and/or video monitor, such
as a digital television (DTV). Supports standard, enhanced,
or high-denition video, plus multi-channel digital audio
on a single cable. It transmits all ATSC HDTV standards and
supports 8-channel digital audio, with bandwidth to spare
to accommodate future enhancements or requirements.
11
12

Asus A52F Specifications

General

Chipset	Intel HM55
Optical Drive	DVD Super Multi
Processor	Intel Core i3-350M
RAM	Up to 8 GB DDR3
Storage	320GB HDD
Display	15.6-inch HD (1366x768)
Graphics	Intel HD Graphics
Operating System	Windows 7 Home Premium
Battery	6-cell, 4400 mAh
Weight	2.62 kg
Card Reader	3-in-1 card reader (SD/MMC/MS)
Camera	0.3 MP
Networking	802.11 b/g/n, 10/100/1000 Base T
Audio	Built-in speaker and microphone
Power Adapter	65W
Ports	3 x USB 2.0, 1 x HDMI, 1 x VGA, 1 x RJ-45, 1 x Headphone-out, 1 x Microphone-in
