1
2
3
5
4
Power (DC) Input
The supplied power adapter converts AC power to DC
power for use with this jack. Power supplied through this
jack supplies power to the Notebook PC and charges the
internal battery pack. To prevent damage to the Notebook
PC and battery pack, always use the supplied power
adapter.
The adapter may become warm to hot when in use. Be sure
not to cover the adapter and keep it away from your body.
USB Port (2.0)
Air Vents
The air vents allow cool air to enter and warm air to exit the
Notebook PC.
Ensure that paper, books, clothing, cables, or other objects
do not block any of the air vents or else overheating may
occur.
Display (Monitor) Output
The 15-pin D-sub monitor port supports a standard VGA-
compatible device such as a monitor or projector to allow
viewing on a larger external display.
HDMI
HDMI Port
DisplayPort Output
DisplayPort is an uncompressed all-digital audio/video
interface between any audio/video source, such as a set-
top box, DVD player, and A/V receiver and an audio and/or
video monitor, such as a digital television (DTV). Supports
standard, enhanced, or high-denition video, plus multi-
channel digital audio on a single cable. It transmits all ATSC
HDTV standards and supports 8-channel digital audio, with
bandwidth to spare to accommodate future enhancements
or requirements.
6
