Asus AM1M-A User Manual

ASUS AM1M-A 2-23
Q-Fan Profile [Standard]
This item appears when you set CPU Q-Fan Control to [PWM Mode] or [DC Mode]
and allows you to set the appropriate performance level of the CPU fan.
[Standard] Sets to [Standard] to make the CPU fan automatically adjust depending on
the CPU temperature.
[Silent] Sets to [Silent] to minimize the fan speed for quiet CPU fan operation.
[Turbo] Sets to [Turbo] to achieve maximum CPU fan speed.
[Manual] Sets to [Manual] to assign detailed fan speed control parameters.
The following four items appear only when you set Q-Fan Prole to [Manual].
Q-Fan Upper Temperature [70]
Use the <+> and <-> keys to adjust the upper limit of the CPU temperature. The values range
from 20ºC to 75ºC.
Q-Fan Max. Duty Cycle(%) [100]
Use the <+> and <-> keys to adjust the maximum CPU fan duty cycle. The values range from
0% to 100%. When the CPU temperature reaches the upper limit, the CPU fan will operate at
the maximum duty cycle.
Q-Fan Lower Temperature [20]
Use the <+> and <-> keys to adjust the lower limit of the CPU temperature. The values range
from 20ºC to 75ºC.
Q-Fan Min. Duty Cycle(%) [20]
Use the <+> and <-> keys to adjust the minimum CPU fan duty cycle. The values range from
0% to 100%. When the CPU temperature is under the lower limit, the CPU fan will operate at the
minimum duty cycle.
2.7.4 Chassis Q-Fan Control [Enabled]
[Disabled] Disables the Chassis Q-Fan control feature.
[PWM Mode] Enables the Chassis Q-Fan control feature in PWM mode for a 4-pin CPU
fan.
[DC Mode] Enables the Chassis Q-Fan control in DC mode for a 3-pin CPU fan.
Fan Speed Low Limit [600 RPM]
This item appears when you set CPU Q-Fan Control to [PWM Mode] or [DC Mode]
and allows you to disable or set the chassis fan warning speed.
Conguration options: [Ignore] [200RPM] [300 RPM] [400 RPM] [500 RPM] [600 RPM]
Q-Fan Profile [Standard]
This item appears only when you enable the Chassis Q-Fan Control feature and allows
you to set the appropriate performance level of the chassis fan.
[Standard] Sets to [Standard] to make the chassis fan automatically adjust
depending on the chassis temperature.
[Silent] Sets to [Silent] to minimize the fan speed for quiet chassis fan
operation.
[Turbo] Sets to [Turbo] to achieve maximum chassis fan speed.
[Manual] Sets to [Manual] to assign detailed fan speed control parameters.

Asus AM1M-A Specifications

General

Non-ECC	Yes
Flash memory	64 MB
Memory channels	Single-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	1333, 1600, 1866 MHz
Supported memory module capacities	16GB, 4GB, 8GB
Processor socket	Socket AM1
Processor manufacturer	AMD
Compatible processor series	AMD Athlon, AMD Sempron
Maximum number of SMP processors	1
Number of Parallel ATA connectors	0
Supported storage drive interfaces	SATA III
USB 2.0 ports quantity	4
LAN controller	Realtek 8111GR
Ethernet interface type	Gigabit Ethernet
Component for	PC
Power source type	ATX
Motherboard chipset	-
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Parallel processing technology support	Not supported
BIOS type	UEFI AMI
ACPI version	2.0a

Weight and Dimensions

Depth	170 mm
Width	226 mm
