1-14

Chapter 1: Product introduction

Audio 2.1, 4.1, 5.1, or 7.1-channel configuration

Port

Headset

2.1-channel

4.1-channel 5.1-channel 7.1-channel

LightBlue(Rearpanel) LineIn RearSpeakerOut RearSpeakerOut RearSpeakerOut

Lime(Rearpanel) LineOut FrontSpeakerOut FrontSpeakerOut FrontSpeakerOut

Pink(Rearpanel) MicIn MicIn Bass/Center Bass/Center

Lime(Frontpanel) - - - SideSpeakerOut

To configure a 7.1-channel audio output:

 UseachassiswithHDaudiomoduleinthefrontpaneltosupporta7.1-channelaudio

output.

7. USB 2.0 ports.These4-pinUniversalSerialBus(USB)portsareforUSB2.0/1.1

devices.

8. USB 3.0 ports.These9-pinUniversalSerialBus(USB)portsareforUSB3.0devices.

• USB3.0devicescanonlybeusedfordatastorage.

• WestronglyrecommendthatyouconnectUSB3.0devicestoUSB3.0portsforfaster

andbetterperformancefromyourUSB3.0devices.

• DuetothedesignoftheIntel

100serieschipset,allUSBdevicesconnectedtothe

USB2.0andUSB3.0portsarecontrolledbythexHCIcontroller.SomelegacyUSB

devicesmustupdatetheirrmwareforbettercompatibility.

9. 5Gb/s Type C USB port.ThisUniversalSerialBus(USB)TypeCportisforTypeC

USBmobileorperipheraldevices.

10. DVI-D port. ThisportisforanyDVI-Dcompatibledevice.DVI-Dcan’tbeconvertedto

outputRGBSignaltoCRTandisn’tcompatiblewithDVI-I.

Multi-VGAoutputsupportsuptothreedisplaysunderWindows

OSenvironment,two

displaysunderBIOS,andonedisplayunderDOS.

Asus B150-PLUS User Manual
