Asus DSL-AC88U User Manual

31
Using USB application
The USB application menu displays several options including
AiDisk, Servers Center, and Network Printer Server.
Using AiDisk for File Sharing
AiDisk allows you to share files stored in a connected USB storage
device through the network.
Before using AiDisk, connect a USB storage device, such as a
USB hard disk or USB flash drive, to the USB 3.0 port on the rear
panel of your wireless router. The USB storage device should be
formatted and partitioned properly. Refer to the
Plug-n-Share
Disk Support List
for disk format, file and partition size at
http://event.asus.com/networks/disksupport
To avoid data loss or damage to the USB storage device, always
follow the steps to safely remove your USB device.

Asus DSL-AC88U Specifications

General

Ethernet WAN	Yes
SIM card slot	No
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	13 channels
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	3167 Mbit/s
WLAN data transfer rate (first band)	1000 Mbit/s
WLAN data transfer rate (second band)	2167 Mbit/s
VPN support	‧VPN server(PPTP/Open VPN) ‧VPN client(PPTP/L2TP/Open VPN)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
RJ-11 ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	5
Security algorithms	WPA-PSK, WPA2-PSK
Antennas quantity	4
AC input voltage	110 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Cables included	AC, DSL, LAN (RJ-45)
Product type	Tabletop router
Product color	Black
LED indicators	DSL, LAN, Power, WLAN
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	180 mm
Width	292 mm
Height	61 mm
Weight	795 g
