2-14 ASUS F1A55-M LK R2.0
2.4.6 DRAM Timing Control
The sub-items in this menu allow you to set the DRAM timing control features. Use the <+>
and <-> keys to adjust the value. To restore the default setting, type [auto] using the keyboard
and press <Enter>.
Changing the values in this menu may cause the system to become unstable! If this
happens, revert to the default settings.
2.4.7 DIGI+ VRM
Load-Line Calibration [Auto]
Load-line is dened by Intel VRM specications, and affects CPU voltage. The CPU working
voltage will decrease proportionally to CPU loading. Higher value gets a higher voltage, and
a better overclocking performance, but increases the CPU and VRM thermal conditions.
This item allows you to adjust the voltage range from the following percentages to boost the
system performance: 0% (Regular), 25% (Medium), 50% (High), 75% (Ultra High) and 100%
(Extreme). Conguration options: [Auto] [Regular] [Medium] [High] [Ultra High] [Extreme]
The actual performance boost may vary depending on your CPU specication.
CPU/NB Load-Line Calibration [Auto]
Allows you to select the CPU/NB Load-line mode. Conguration options: [Auto] [Regular]
[High] [Extreme]
VRM Fixed Frequency [xxx]
Allows you to set a xed VRM frequency. Use the <+> and <-> keys to adjust the value. The
values range from 250k Hz to 400k Hz with a 50k Hz interval.
CPU Power Phase Control [Standard]
Allows you to control the power phase based on the CPU’s demands. Conguration options:
[Standard] [Optimized] [Extreme] [Manual Adjustment]
DO NOT remove the thermal module when switching to Extreme and Manual Mode. The
thermal conditions should be monitored.
2.4.8 CPU Voltage [Offset Mode]
[Offset Mode] To offset the voltage by a positive or negative value.
CPU Offset Mode Sign [+]
[+] To offset the voltage by a positive value.
[–] To offset the voltage by a negative value.
