4. Expansion slots
The motherboard has one PCI slot.
To install and configure an expansion card:
1. Install an expansion card following the instructions that came with the
chassis.
2. Turn on the system and change the necessary BIOS settings, if any.
3. Assign an IRQ to the card. Refer to the tables below.
4. Install the drivers and/or software applications for the expansion card
according to the card documentation.
Standard interrupt assignmentsStandard interrupt assignments
Standard interrupt assignmentsStandard interrupt assignments
Standard interrupt assignments
IRQIRQ
IRQIRQ
IRQ
Standard FunctionStandard Function
Standard FunctionStandard Function
Standard Function
0 System Timer
2 Programmable Interrupt Controller
3 AHPC IRQ Holder for PCI IRQ Steering
3 Intel
®
82801FB/FBM PCI Express Root Port - 2660
3 Intel
®
82801FB/FBM USB Universal Host Controller - 265B
3 Intel
®
915G Graphics Controller 0
5 AHPC IRQ Holder for PCI IRQ Steering
5 AHPC IRQ Holder for PCI IRQ Steering
5 Intel
®
82801FB/FBM PCI Express Root Port - 2662
5 Intel
®
82801FB/FBM USB Universal Host Controller - 2658
5 Intel
®
82801FB/FBM USB2 Enhanced Host Controller - 265C
8 System CMOS/Real Time Clock
9 SCI IRQ Used by ACPI Bus
10 AHPC IRQ Holder for PCI IRQ Steering
10 AHPC IRQ Holder for PCI IRQ Steering
10 VIA OHCI Compliant IEEE 1394 Host Controller
10 Intel
®
82801FB/FBM PCI Express Root Port - 2666
10 Intel
®
82801FB/FBM Ultra ATA Storage Controllers - 2659
11 AHPC IRQ Holder for PCI IRQ Steering
11 Intel
®
82801FB/FBM PCI Express Root Port - 2664
11 Intel
®
82801FB/FBM USB Universal Host Controller - 265A
12 Microsoft
®
Port Mouse
13 Numeric Data Processor
14 Intel
®
82801FB/FBM Ultra ATA Storage Controllers - 266F
14 Intel
®
82801FB Ultra ATA Storage Controllers - 2652
