The conguration options for the following sub-items vary depending on the CPU/DIMMs
you install on the motherboard.
OC From CPU Level UP [Auto]
This item appears only when you set the CPU OverClocking item to [Manual] and allows you
to select a CPU level. The related parameters will be automatically adjusted according to the
selected CPU level.
CPU/HT Reference Clcok (MHz) [XXX]
This item appears only when you set the CPU OverClocking item to [Manual] or [D.O.C.P]
and displays the frequency sent by the clock generator to the system bus and PCI bus. Usedisplays the frequency sent by the clock generator to the system bus and PCI bus. Use
the <+> and <-> keys to adjust the CPU Bus frequency. You can also key in the desired
frequency using the numeric keypad. The values range from 100 to 550.
PCIE Frequency [XXX]
This item appears only when you set the CPU OverClocking item to [Manual] and allows youallows you
to set the PCI Express frequency. Use the <+> and <-> keys to adjust the PCIE frequency.
You can also key in the desired value using the numeric keypad. The values range from 100
to 150.
3.5.2 CPU OverClocking [Auto]
Allows you to select the CPU overclocking options to achieve the desired CPU internal
frequency. Select any of these preset overclocking conguration options:
Manual Allows you to individually set overclocking parameters.
Auto Loads the optimal settings for the system.
D.O.C.P
Allows you to select a DRAM O.C. prole, and the related parameters
will be adjusted automatically.
CPU Level UP
Allows you to select a CPU level, and the related parameters will be
adjusted automatically.
Overclock Prole Allows you to select an overclocking prole.
3.5.1 CPU Level UP [Auto]
Allows you to select a CPU level, and the related parameters will be automatically adjusted
according to the selected CPU level. If you want to manually congure the settings in detail,
set CPU Overclocking to [Manual] after selecting a CPU level.
Conguration options: [Auto] [Phenom II-955] [Phenom II-3.4G] [Phenom II-3.6G]
• The conguration options vary depending on the CPU model you install on the
motherboard.
• The CPU Level UP function support depends on CPU types.
